2500PPR Rotary Encoder OMRON Incremental E6B2-CWZ6C in Pakistan

Description

Incremental Encoders output a pulse string according to the rotational displacement of an axis. The number of rotations can be detected by counting the number of pulses.

Specification:

• Series : E6B
• Encoding Method: Incremental
• Resolution P/R: 2500
• Control Output (Output type): NPN open collector output
• Max Force Radial: 30 N
• Max Force Thrust: 20 N
• IP Rating : IP50
• Power Supply Voltage: 5 VDC -5% to 24 VDC +15% (ripple (p-p): 5% Max.)
• Max Rotation Frequency r/min: 6000 r/min
• Height (mm): 40
• Width (mm): 40
• Depth (mm): 39
• Weight (kg): 0.252



Packages Include:

 1 x 2500PPR Rotary Encoder OMRON Incremental E6B2-CWZ6C
