UT81C Scope Digital Multimeter in Pakistan

Description

UT81C Scope Digital Multimeter BR2386

 UT81 series handheld digital oscilloscope multimeters combine oscilloscope and digital multimeter in one. Oscilloscope measurement mode includes signal input, data processing, auto measure, waveform storage, and transfer.

 Multimeter mode features AC/DC voltage and current, resistance, diode, continuity, frequency, duty ratio, and capacitance.

 Technical Information

 Specifications Range UT81C
 DMM Specifications
 DC voltage (V) 1000V ±(0.8%+8)
 AC voltage (V) 750V ±(1%+15)
 DC current (A) 10A ±(1%+8)
 AC current (A) 10A ±(1.5%+8)
 Resistance (?) 40M? ±(1%+5)
 Capacitance (F) 100?F ±(3%+8)
 Frequency (Hz) 10Hz~10MHz ±(0.1%+3)
 Scope Specifications
 Bandwidth ? 16MHz
 Sampling rate ? 80MS/s
 Vertical accuracy ? ±(5%+1)
 Vertical sensitivity 20mV/div~500V/div (1-2-5) ?
 Time-base accuracy ? ±(0.01%+1)
 Time-base range 50ns/div – 5s/div(1-2-5)
 Features
 Display count ? 4000
 Auto range ? ?
 Duty cycle 0.1~99.9% ?
 Diode ? ?
 Auto power off ? ?
 Continuity buzzer ? ?
 Display 160 x 160 monochrome ?
 Trigger types Auto run/Normal/Single shot ?
 Memory 10 screens and setups ?
 Contrast and brightness setup ? ?
 Low battery indication ? ?
 USB interface ? ?
 LCD backlight ? ?
 Input impedance for DCV Around 10M? ?
 General Characteristics
 Power 1.5V battery (R6) x 4
 Display 60mm x 60mm
 Product color Red and grey
 Product net weight 498g
 Product size 200mm x 100mm x 48mm
 Standard accessories Batteries, test lead, alligator clip, USB interface cable, PC software CD
 Standard individual packing Gift box, English manual
 Standard quantity per carton 12pcs
 Standard carton measurement 485mm x 450mm x 260mm (0.057CBM per standard carton)
