Description
YIHUA 60V 5A Digital Precision DC Power Supply in Pakistan BR1607
Features:
- YIHUA60V 5A is the second generation of digital program-controlled switching power supply, it used the latest technology and crafts.
- This digital program-controlled stabilized switching power supply is designed for use in laboratories, schools,
- production lines, and electronic repair.
- It has a small size and is lightweight, which is very easy to transport and carry.
- It has high efficiency, high load capacity, and low noise and is superior to linear power supplies.
- It has high voltage stability, small ripple factor, excellent short circuit protection, and over-current protection.
Machine parameters
|
|
| rated voltage | AC220V 50Hz |
| Power of complete machine | 380W |
| Operating environment | 0?40? relative humidity ?80? |
| Storage Temperature | ?20?80? relative humidity ?80? |
| Dimensions | 255*130*150mm |
| weight | 3.1KG |
Specifications
|
|
| output voltage | Adjustable continuously within 0?60V |
| output current | Adjustable continuously within 0?5A |
| output power | 300W |
| Source effect | 1mV |
| load effect | ?0.33% |
| Ripple noise | ?3mVrms?5Hz ~ 1MHz?/?3mArms |
| Display accuracy | 0.1V/0.1A/1mA |
| Protection mode | Over-current, short circuit, over-temperature protection |
| Dissipation mode | air cooling |
Packages Include:
1 x YIHUA 60V 5A Digital Precision DC Power Supply
